Smart Tint wiring and voltages
For multiple pieces of material all wiring should be connected in parallel and
(NOT Daisy Chained or run in series)
Please contact a licensed electrician with any wiring or operating concerns.
When installing multiple pieces of material it is mandatory that
wiring should be in a parallel circuit and
NOT DAISY CHAINED IN SERIES.
This diagram applies to all of our material both our low voltage and 120 vac line voltage
